Mainboard ASUS TUF X299 MARK 1

Mô tả

• CPU
  Build in Intel® Socket 2066 Core™ X-Series Processors
  * The Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types
  * Refer to www.asus.com for CPU support list
• Chipset
  Build in Intel® X299
• Memory
  Intel® Core™ X-series Processors (6-core above)
  8 x DIMM, Max. 128GB, DDR4 4000(O.C.)/3600(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
  Intel® Core™ X-series Processors (4-core)
  4 x DIMM, Max. 64GB, DDR4 4000(O.C.)/3600(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
  ** Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
• Multi-GPU Support
  Supports NVIDIA® Quad-GPU SLI™ Technology
  Supports NVIDIA® 3-Way SLI™ Technology
  Supports NVIDIA® 2-Way SLI™ Technology
  Supports AMD Quad-GPU CrossFireX™ Technology
  Supports AMD 3-Way CrossFireX™ Technology
• Expansion Slots
  44-Lane CPU-
  3 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x16/x8)
  2 x PCIe 3.0 x4 (max at x4 mode) *¹
  28-Lane CPU-
  3 x PCIe 3.0/2.0 x16 ( x16, x16/x8, x16/x8/x4)
  2 x PCIe 3.0 x4 (max at x4 mode) *¹
  16-Lane CPU-
  3 x PCIe 3.0/2.0 x16 (x16, x8/x8, x8/x8/x1)
  2 x PCIe 3.0 x4 (max at x4 mode) *¹
• Storage
  Intel® X299 Chipset :
  1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
  8 x SATA 6Gb/s port(s)
  Support Raid 0, 1, 5, 10
  Supports Intel® Smart Response Technology, Intel Rapid Start Technology*²
  Intel® Optane™ Memory Ready
• LAN
  Intel® I219V, 1 x Gigabit LAN Controller(s), featuring Turbo LAN
  Intel® I211, 1 x Gigabit LAN, featuring Turbo LAN
  ASUS Turbo LAN Utility
• Audio
  Realtek® ALC S1220A 8-Channel High Definition Audio CODEC
  – Impedance sense for front and rear headphone outputs
  – Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
  – Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  Audio Feature :
  – DTS Connect
  – DTS Headphone:X
  – Optical S/PDIF out port(s) at back panel
  – Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
  – Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
  – Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
  – Unique de-pop circuit: Reduces start-up popping noise to audio outputs
  – EMI protection cover to prevent electrical noise to affect the amplifier quality
  Separate layer for left and right track, ensuring both sound deliver equal quality
• USB Ports
  ASMedia® USB 3.1 Gen 2 controller :
  1 x USB 3.1 Gen 2 port(s) (1 at mid-board)
  ASMedia® USB 3.1 Gen 2 controller :
  2 x USB 3.1 Gen 2 port(s) (Type-A + USB Type-C^TM)
  Intel® X299 Chipset :
  8 x USB 3.1 Gen 1 port(s) (4 at back panel, , 4 at mid-board)
  Intel® X299 Chipset :
  6 x USB 2.0 port(s) (4 at back panel, , 2 at mid-board)
• Special Features

  OC Design – ASUS PRO Clock Technology

  TUF Features:
  TUF ENGINE! Power Design :
  – 8 +2 Digital Phase Power Design
  – TUF Components (Choke, Cap. & MOSFET; certified by military-standard)
  Ultimate COOL! Thermal Solution :
  – TUF Thermal Armor
  Thermal Radar 3
  – TUF ICe
  Safe & Stable! Guardian Angel :
  “We Got Your Back!” Shape Force
  – Dust Defenders
  – TUF Fortifier
  TUF VGA Holder
  – TUF ESD Guards 2
  – TUF LANGuard
  AURA :
  – Aura RGB Strip Headers
  – Aura Lighting Effects Synchronization with compatible ASUS ROG devices
  ASUS Exclusive Features :
  – USB BIOS Flashback
  – MemOK!
  – AI Suite 3
  – Ai Charger
  – Onboard Button : Power
  – ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
  – Turbo LAN

  ASUS EZ DIY :
  – ASUS EZ Flash 3
  – ASUS USB BIOS Flashback
  – ASUS UEFI BIOS EZ Mode
  – Multi-language BIOS
  ASUS Q-Design :
  – ASUS Q-Shield
  – ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED, HDD LED)
  – ASUS Q-Slot
  – ASUS Q-DIMM
  – ASUS Q-Connector
  M.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds)

• Back I/O Ports
  2 x LAN (RJ45) port(s)
  2 x USB 3.1 Gen 2 Type-A + USB Type-C^TM
  4 x USB 3.1 Gen 1
  4 x USB 2.0 (one port can be switched to USB BIOS Flashback)
  1 x Optical S/PDIF out
  5 x Audio jack(s)
  1 x USB BIOS Flashback Button(s)
  1 x TUF Detective USB port
• Internal I/O Ports
  1 x AAFP connector
  1 x Aura RGB Strip Header
  2 x USB 3.1 Gen 1 connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s)
  1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
  1 x TPM header
  1 x COM port(s) connector(s)
  8 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s)
  1 x CPU OPT Fan connector(s)
  5 x Chassis Fan connector(s)
  1 x Assistant Fan connector(s)
  1 x H_AMP fan connector
  1 x W_PUMP+ connector
  1 x Thunderbolt header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x 4-pin ATX 12V Power connector(s)
  1 x System panel(s) (Q-Connector)
  1 x MemOK! button(s)
  3 x Thermal sensor connector(s)
  1 x Power-on button(s)
  1 x Clear CMOS jumper(s)
  1 x USB 3.1 Gen 2 front panel connector
  1 x CPU_OV jumper
• Accessories
  User’s manual
  ASUS Q-Shield
  1 x Vertical M.2 bracket set
  4 x SATA 6Gb/s cable(s)
  1 x ASUS 2-Way/3-Way SLI bridge
  1 x M.2 Screw Package
  1 x Supporting DVD
  1 x SLI HB BRIDGE(2-WAY-M)
  1 x Q-Connector
  1 x TUF Certification card(s)
  1 x TUF 5 Year Warranty manual(s) (by region)
  1 x TUF Inside sticker(s)(white)
  1 x STAY COOL BE TUF sticker(s)(gray)
  1 x TUF Dongle
  1 x Accessory Package(s):
  – 3 x PCIe x16 slot dust cover(s)
  – 2 x PCIe x4 slot dust cover(s)
  1 x TUF VGA Holder
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS,
  ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen and ASUS DRAM SPD (Serial Presence Detect) memory information
• Manageability
  WfM 2.0, DMI 3.0, WOL by PME, PXE
• Support Disc
  Drivers
  ASUS Utilities
  EZ Update
  Anti-virus software (OEM version)
• Operating System
  Windows® 10 64-bit
• Form Factor
  ATX Form Factor
  12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
• Note
  1. PCIEX4_1 max. at x1 mode, PCIEX4_2 max. at x4 mode
  2. SATA6G_4/5/6/7 share bandwidth with PCIEX4_2.
